| b Belt width, mm |
6 |
8 |
10 |
12 |
16 |
20 |
25 |
| B Pulley width, mm |
12 |
13 |
15 |
17 |
21 |
25 |
30 |
| Special widths on request |
| Tolerances
for belt width |
±0,5 |
| Tolerances
for nominal thickness hs |
±0,15 |
Min. diameter
of the Idler Pulley placed inside the belt = 60 mm
Min. diameter of the Idler Pulley placed outside the belt =
60 mm |
|
|
| CODE |
LENGTH(mm) |
nº TEETH (z) |
| 225 |
225 |
45 |
| 255 |
255 |
51 |
| 280 |
280 |
56 |
| 300 |
300 |
60 |
| 330 |
330 |
66 |
| 340 |
340 |
68 |
| 375 |
375 |
75 |
| 390 |
390 |
78 |
| 420 |
420 |
84 |
| 450 |
450 |
90 |
| 455 |
455 |
91 |
| 500 |
500 |
100 |
| 525 |
525 |
105 |
| 545 |
545 |
109 |
| 600 |
600 |
120 |
| 610 |
610 |
122 |
| 660 |
660 |
132 |
| 710 |
710 |
142 |
| 720 |
720 |
144 |
| 750 |
750 |
150 |
| 780 |
780 |
156 |
| 825 |
825 |
165 |
| 860 |
860 |
172 |
| 975 |
975 |
195 |
| 1050 |
1050 |
210 |
| 1125 |
1125 |
225 |
| 1220 |
1220 |
122 |
| 1480 |
1480 |
148 |
| 1500 |
1500 |
300 |
| 2000 |
2000 |
400 |
|
|
|
