| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
10 |
16 |
25 |
32 |
50 |
75 |
100 |
150 |
| MAX TRACTION LOAD (N) |
640 |
1100 |
1820 |
2350 |
3950 |
5750 |
7600 |
11500 |
| BELT WEIGHT (gr./mt) |
30 |
48 |
75 |
96 |
160 |
245 |
328 |
490 |
| WIDTH TOLERANCE [mm] |
±0,5 |
| THICKNESS TOLERANCE [mm] |
±0,2 |
 |
| • minimum no of teeth pulley accepted |
z |
12 |
|
| • minimum diameter for inside idler |
Ø |
25 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
15 |
|
| • minimum diameter for outside idler |
Ø |
60 |
mm |
|
|
