| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
|
|
|
|
|
|
|
|
150 |
| MAX TRACTION LOAD (N) |
|
|
|
|
|
|
|
|
23800 |
| WIDTH TOLERANCE [mm] |
±0,5 |
| THICKNESS TOLERANCE [mm] |
±0,3 |
 |
| • minimum no of teeth pulley accepted |
z |
25 |
|
| • minimum diameter for inside idler |
Ø |
80 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
- |
|
|
| • minimum diameter for outside idler |
Ø |
120 |
mm |
|
|
