| b Belt width, inches |
050 |
075 |
100 |
| b Belt width, mm |
12,7 |
19,1 |
25,4 |
| B Pulley width,mm |
19 |
25,4 |
29,7 |
| Special widths on request |
| Tolerances
for belt width |
±0,8 |
| Tolerances
for nominal thickness hs |
±0,3 |
Min. diameter
of the Idler Pulley placed inside the belt = 60 mm
Min. diameter of the Idler Pulley placed outside the belt =
60 mm |
|
|
| CODE |
LENGTH(mm) |
nº TEETH (z) |
| 86 |
218,6 |
23 |
| 124 |
314,3 |
33 |
| 150 |
381 |
40 |
| 187 |
476,2 |
50 |
| 202 |
514,4 |
54 |
| 210 |
533,4 |
56 |
| 225 |
571,5 |
60 |
| 240 |
609,6 |
64 |
| 255 |
647,7 |
68 |
| 270 |
685,8 |
72 |
| 285 |
723,9 |
76 |
| 300 |
762 |
80 |
| 322 |
817,88 |
86 |
| 345 |
876,3 |
92 |
| 367 |
933,4 |
98 |
| 390 |
990,6 |
104 |
| 420 |
1066,8 |
112 |
| 450 |
1143 |
120 |
| 480 |
1219,2 |
128 |
| 510 |
1295,4 |
136 |
| 540 |
1371,6 |
144 |
| 570 |
1447,8 |
152 |
| 600 |
1524 |
160 |
|
|
|
