WIDTH
[mm] |
MAX
TRACTION
LOAD
[N] |
MAX
TRACTION
LOAD
JOINED
[N] |
BREAKING
STRENGTH
[N] |
BELT WEIGHT
[kg/m] |
| 12 |
1280 |
/ |
4020 |
0,054 |
| 16 |
1630 |
815 |
5110 |
0,072 |
| 25 |
2560 |
1280 |
8040 |
0,133 |
| 32 |
3370 |
1685 |
10600 |
0,144 |
| 50 |
5230 |
2615 |
16450 |
0,256 |
| 75 |
8260 |
4130 |
25960 |
0,398 |
| 100 |
10470 |
5235 |
32900 |
0,530 |
| 150 |
12000 |
6000 |
38000 |
1,2 |
| 200* |
7500 |
3750 |
28500 |
1,6 |
|
|
 |
|
 |
|
| Tolerance for belt width |
±0,5 |
| Tolerance for nominal thickness |
±0,15 |
|
|
|
