| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
10 |
16 |
25 |
32 |
50 |
75 |
100 |
150 |
| MAX TRACTION LOAD (N) |
|
1980 |
3330 |
4380 |
7500 |
11500 |
15300 |
23800 |
| BELT WEIGHT (gr./mt) |
80 |
128 |
200 |
250 |
400 |
600 |
800 |
1100 |
| WIDTH TOLERANCE [mm] |
±1,0 |
| THICKNESS TOLERANCE [mm] |
±0,45 |
 |
| • minimum no of teeth pulley accepted |
z |
15 |
|
| • minimum diameter for inside idler |
Ø |
120 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
25 |
|
| • minimum diameter for outside idler |
Ø |
120 |
mm |
|
|
