| WIDTH (mm) |
MAX TRACTION LOAD (N) |
BREAKING STRENGTH (N) |
| 25 | 3660 | 12460 |
| 32 | 4880 | 16620 |
| 50 | 8050 | 27430 |
| 75 | 12200 | 41560 |
| 100 | 16100 | 54860 |
| 150 | 25300 | 86400 |
 |
| Tolerances for belt width | ±0,5 |
| Tolerances for nominal thickness | ±0,45 |
|
| Min. number of teeth and outside diameter | Z=15Φ 92.65 mm |
| Φ Min. inside idler | Φ 120 |
| Φ Min. outside idler | Φ 120 |
|
