| WIDTH (mm) |
MAX TRACTION LOAD (N) |
BREAKING STRENGTH (N) |
| 32 | 1290 | 3890 |
| 50 | 1970 | 5970 |
 |
| Tolerances for belt width | ±0.5 |
| Tolerances for nominal thickness | ±0.15 |
|
| Min. number of teeth and outside diameter | Z=10Φ 15.05 mm |
| Φ Min. inside idler | Φ 30 |
| Φ Min. outside idler | Φ 30 |
|
