3M timing pulleys

3M 09

Material
Pulley Type
Designation
N. Of Teeth
PD
(mm)
OD
(mm)
FD
(mm)
HD
(mm)
F
(mm)
L
(mm)
b
(mm)
Weight (kg)
Aluminum
1F
10 3M 9 - 1F
10
9.55
8.79
13
13
10.2
17.5
-
0.004
Aluminum
1F
12 3M 9 - 1F
12
11.46
10.7
15
15
10.2
17.5
-
0.006
Aluminum
1F
14 3M 9 - 1F
14
13.37
12.61
16
16
10.2
17.5
-
0.007
Aluminum
1F
15 3M 9 - 1F
15
14.32
13.56
17.5
17.5
10.2
17.5
-
0.008
Aluminum
6F
16 3M 9 - 6F
16
15.28
14.52
18
10
12.8
20.6
4
0.005
Aluminum
6F
18 3M 9 - 6F
18
17.19
16.43
19.5
11
12.8
20.6
6
0.008
Aluminum
6F
20 3M 9 - 6F
20
19.1
18.34
23
13
12.8
20.6
6
0.011
Aluminum
6F
21 3M 9 - 6F
21
20.05
19.29
25
14
12.8
20.6
6
0.013
Aluminum
6F
22 3M 9 - 6F
22
21.01
20.25
25
14
12.8
20.6
6
0.013
Aluminum
6F
24 3M 9 - 6F
24
22.92
22.16
25
14
12.8
20.6
6
0.015
Aluminum
6F
26 3M 9 - 6F
26
24.83
24.07
28
16
12.8
20.6
6
0.018
Aluminum
6F
28 3M 9 - 6F
28
26.74
25.98
32
18
12.8
20.6
6
0.024
Aluminum
6F
30 3M 9 - 6F
30
28.65
27.89
32
20
12.8
20.6
6
0.028
Aluminum
6F
32 3M 9 - 6F
32
30.56
29.8
36
22
12.8
20.6
6
0.032
Aluminum
6F
36 3M 9 - 6F
36
34.38
33.62
38
26
13.4
22.2
6
0.05
Aluminum
6F
40 3M 9 - 6F
40
38.2
37.44
42
28
13.4
22.2
6
0.06
Aluminum
6F
44 3M 9 - 6F
44
42.02
41.26
48
33
13.4
22.2
6
0.07
Aluminum
6
48 3M 9 - 6
48
45.84
45.08
-
33
13.4
22.2
8
0.107
Aluminum
6
60 3M 9 - 6
60
57.3
56.54
-
33
13.4
22.2
8
0.11
Aluminum
6
72 3M 9 - 6
72
68.75
67.99
-
33
13.4
22.2
8
0.15
