5M timing bars

5M Pitch 5mm

Material
Designation
N. of teeth
PD
(mm)
OD
(mm)
UL
(mm)
L
(mm)
Aluminum
5M -12
12
19.1
17.96
150
165
Aluminum
5M -13
13
20.69
19.55
150
165
Aluminum
5M -14
14
22.28
21.14
175
183
Aluminum
5M -15
15
23.87
22.73
175
183
Aluminum
5M -16
16
25.46
24.32
175
183
Aluminum
5M -17
17
27.06
25.92
175
183
Aluminum
5M -18
18
28.65
27.51
200
200
Aluminum
5M -19
19
30.24
29.1
200
200
Aluminum
5M -20
20
31.83
30.69
200
200
Aluminum
5M -21
21
33.42
32.28
200
200
Aluminum
5M -22
22
35.01
33.87
200
200
Aluminum
5M -23
23
36.61
35.47
200
200
Aluminum
5M -24
24
38.2
37.06
200
200
Aluminum
5M -25
25
39.79
38.65
200
200
Aluminum
5M -26
26
41.38
40.24
200
200
Aluminum
5M -27
27
42.97
41.83
200
200
Aluminum
5M -28
28
44.56
43.42
200
200
Aluminum
5M -29
29
46.15
45.01
200
200
Aluminum
5M -30
30
47.75
46.6
200
200
Aluminum
5M -31
31
49.34
48.2
200
200
Aluminum
5M -32
32
50.93
49.79
200
200
Aluminum
5M -33
33
52.52
51.38
200
200
Aluminum
5M -34
34
54.11
52.97
200
200
Aluminum
5M -35
35
55.7
54.56
200
200
Aluminum
5M -36
36
57.3
56.16
200
200
Aluminum
5M -38
38
60.48
59.34
200
200
Aluminum
5M -40
40
63.66
62.52
200
200
Aluminum
5M -42
42
66.85
65.71
200
200
Aluminum
5M -44
44
70.03
68.89
200
200
Aluminum
5M -45
45
71.62
70.48
200
200
Aluminum
5M -46
46
73.21
72.07
200
200
Aluminum
5M -48
48
76.39
75.25
200
200
Aluminum
5M -50
50
79.58
78.43
200
200
Aluminum
5M -54
54
85.94
84.8
200
200
Aluminum
5M -60
60
95.49
94.35
200
200
Aluminum
5M -62
62
98.68
97.54
200
200
Aluminum
5M -72
72
114.59
113.45
200
200
