| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
10 |
16 |
25 |
32 |
50 |
75 |
100 |
150 |
| MAX TRACTION LOAD (N) |
|
1980 |
3330 |
4380 |
7500 |
11500 |
15300 |
23800 |
| BELT WEIGHT (gr./mt) |
60 |
97 |
150 |
190 |
300 |
450 |
600 |
900 |
| WIDTH TOLERANCE [mm] |
±0,5 |
| THICKNESS TOLERANCE [mm] |
±0,3 |
 |
| • minimum no of teeth pulley accepted |
z |
15 |
|
| • minimum diameter for inside idler |
Ø |
50 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
25 |
|
| • minimum diameter for outside idler |
Ø |
120 |
mm |
|
|
