| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
|
12.7 |
19.1 |
25.4 |
38.1 |
50.8 |
76.2 |
101.6 |
152.4 |
| MAX TRACTION LOAD (N) |
|
610 |
1030 |
1430 |
2250 |
3070 |
4710 |
6350 |
9640 |
| WIDTH TOLERANCE [mm] |
±0,5 |
| THICKNESS TOLERANCE [mm] |
±0,3 |
| WIDTH BELT (inch) |
025 |
037 |
050 |
075 |
100 |
150 |
200 |
300 |
400 |
600 |
| BELT WEIGHT (gr./mt) |
|
33 |
45 |
68 |
90 |
135 |
180 |
270 |
360 |
540 |
 |
| • minimum no of teeth pulley accepted |
z |
15 |
|
| • minimum diameter for inside idler |
Ø |
60 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
20 |
|
| • minimum diameter for outside idler |
Ø |
60 |
mm |
|
|
