WIDTH
[mm] |
MAX
TRACTION
LOAD
[N] |
MAX
TRACTION
LOAD
JOINED
[N] | BREAKING
STRENGTH
[N] | BELT WEIGHT
[kg/m] |
| 25 |
6020 |
3010 |
19630 |
0,282 |
| 40 |
9260 |
4630 |
30200 |
0,451 |
| 55 |
11570 |
5785 |
37760 |
0,620 |
| 85 |
20830 |
10415 |
67960 |
0,958 |
| 100 |
25000 |
12500 |
81560 |
1,127 |
| 115 |
28800 |
14400 |
101000 |
1,426 |
|
|
|
