| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
10 |
15 |
20 |
25 |
30 |
50 |
85 |
100 |
150 |
| MAX TRACTION LOAD (N) |
875 |
1330 |
|
2375 |
2660 |
4750 |
8330 |
9830 |
14800 |
| BELT WEIGHT (gr./mt) |
39 |
59 |
78 |
98 |
125 |
195 |
290 |
390 |
590 |
| WIDTH TOLERANCE [mm] |
±0,5 |
| THICKNESS TOLERANCE [mm] |
±0,2 |
 |
| • minimum no of teeth pulley accepted |
z |
12 |
|
| • minimum diameter for inside idler |
- | |
|
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
15 |
|
| • minimum diameter for outside idler |
Ø |
60 |
mm |
|
|
