TRACTION RESISTANCE |
|
WIDTH BELT (mm) |
10 |
16 |
25 |
32 |
50 |
75 |
100 |
150 |
MAX TRACTION LOAD (N) |
|
1290 |
2130 |
2770 |
4440 |
6750 |
9050 |
13600 |
BELT WEIGHT (gr./mt) |
45 |
72 |
133 |
144 |
256 |
398 |
530 |
750 |
WIDTH TOLERANCE [mm] |
±0,5 |
THICKNESS TOLERANCE [mm] |
±0,3 |
|
minimum no of teeth pulley accepted |
z |
12 |
|
minimum diameter for inside idler |
Ø |
60 |
mm |
|
minimum no of teeth pulley on the
back of double teeth belt
|
z |
20 |
|
minimum diameter for outside idler |
Ø |
60 |
mm |
|
|
