| CODE |
LENGTH(mm) |
nº TEETH (z) |
| 457.5 |
457.5 |
183 |
| b Belt width, mm |
4 |
6 |
8 |
10 |
12 |
| B Pulley width, mm |
8 |
10 |
12 |
14 |
16 |
| Tolerances for belt width |
±0,3 |
| Tolerances for nominal thickness hs |
±0,15 |
Min. diameter of the Idler Pulley placed inside the belt = 20 mm
Min. diameter of the Idler Pulley placed outside the belt = 18 mm |
|
|
