| TRACTION RESISTANCE |
|
| WIDTH BELT (mm) |
|
12.7 |
19.1 |
38.1 |
50.8 |
76.2 |
101.6 |
152.4 |
| MAX TRACTION LOAD (N) |
|
|
|
5570 |
8700 |
12100 |
17200 |
25000 |
| BELT WEIGHT (gr./mt) |
|
132.5 |
199 |
397 |
|
|
|
|
| WIDTH TOLERANCE [mm] |
±1,0 |
| THICKNESS TOLERANCE [mm] |
±0,15 |
 |
| • minimum no of teeth pulley accepted |
z |
18 |
|
| • minimum diameter for inside idler |
Ø |
150 |
mm |
 |
• minimum no of teeth pulley on the
back of double teeth belt
|
z |
25 |
|
| • minimum diameter for outside idler |
Ø |
180 |
mm |
|
|
